How to Read a Tie-up Plan?

Figure 1: Note that, the primary information that can be extracted from the draft below is that there are 4 shafts and 6 treadles in the loom. Out of 6 treadles only 4 are being used to make the desired pattern, however, all 6 could have been used (depending on the pattern requirement). Also, note how treadles are linked with threading shafts (T1 is tied up with shaft 1 and 2 and so on).



A Word about Notations

Notations vary from book to book. The example illustrated in this article uses numbers for threading, colour coding for tie-up and treadling for easier explanation. There are many standard books using their own notations for representational purposes.

For example, The Hand Weaver’s Pattern Directory by Anne Dixon, a famous must have for weavers working on 4 shaft looms, has used colour-coding the boxes for representing threading, tie-up and treadling (■□). All the patterns in this book are for a rising shaft loom.

Another well-noted book- A weaver’s book of 8 shaft Patterns by Carol Strickler– uses numbers to represent threading sequence (as done in the example). However, circles are drawn to represent tie-ups for a rising shaft loom.


You can follow any standard notation or create one of your own. However, do remember to write down the interpretations of the symbols clearly. After all, the purpose of these drafts is to communicate your design to a wider weaver audience!

---
